IP63 1R1G1B Stage Background Led Display Video Wall Seamless SDI

    Buy cheap IP63 1R1G1B Stage Background Led Display Video Wall Seamless SDI from wholesalers

    Buy cheap IP63 1R1G1B Stage Background Led Display Video Wall Seamless SDI from wholesalers
    • Buy cheap IP63 1R1G1B Stage Background Led Display Video Wall Seamless SDI from wholesalers
    • Buy cheap IP63 1R1G1B Stage Background Led Display Video Wall Seamless SDI from wholesalers
    • Buy cheap IP63 1R1G1B Stage Background Led Display Video Wall Seamless SDI from wholesalers

    IP63 1R1G1B Stage Background Led Display Video Wall Seamless SDI

    Ask Lasest Price
    Brand Name : PASSION
    Model Number : P4.81, P6.25
    Certification : CCC, CE, ROHS
    Price : Negotiation
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000Sqm/month
    Delivery Time : 15~25 working days
    • Product Details
    • Company Profile

    IP63 1R1G1B Stage Background Led Display Video Wall Seamless SDI

    P4.81mm Rental LED Display , Stage background LED Wall, Slim Rental LED Video Wall


    Supply Ability: 6000 Square Meter/Square Meters per Month

    Advantages of Rental LED Display:

    Use of Special heat dissipation structure make excellent heat dissipation, Quiet operation without fans.High refresh/High contrast/High grayscale/ Gorgeous picture showing Ultra-wide viewing angle give you the largest screen viewing area.Die-cast aluminum cabinet design light and easy to transport, good flatness and seamless


    Features of Rental LED Display:


    1. Seamless Connection and Easy Installation

    Cabinet Size: 500mm*500mm.

    Seamless connection, 0.1mm gapline between 2 cabinets.

    Fast lock for quick and easy installation.

    Maximum support 50 pcs hanging in a collum.


    2. Support All Media Format and Display Mode

    Support all media format, also support DVI/HDMI/3G/HD/SD/SDI display mode, applicable for TV program, VCD/DVD and live show. Smart mode available (optional) to monitor the overall working hours and temperature of each cabinet. Hotplug in power supply.


    3. Cost Saving for Installation and Maintenance

    Fast locks design, cabinets can be easily assemblied in 7 seconds.

    Dual-maintenance, no need fan, noiseless, low power comsumption.

    Vertical / Horizontal viewing angle 160 degree.

    Calibration for high quality picture.


    Special Features of Rental LED Display:

    1. High quality table lamp, the product quality is stable, reliable, and guaranteed;
    2. Viewing angle of 140 degrees or more, multi direction viewing display effect is consistent;
    3. Integrated blanking circuit, effectively eliminate the ghost line;
    4. Multi rib structure design, to ensure that the product is not easy to tensile deformation, to ensure the integrity of the screen and the consistency of the overall.

    5. Support All Media Format and Display Mode:

    DVI/HDMI/3G/HD/SD/SDI display mode, applicable for TV program,VCD/DVD and live show.

    Smart mode available (optional) to monitor the overall working hours and temperature of each cabinet.


    Detail Specifications of outdoor P4.81mm Slim Rental LED Display:


    ParameterValue
    Physical ParameterPixel Configuration1R1G1B
    Pixel Pitch (mm)4.81
    Pixel Matrix per m2 (dots)43264
    Pixel Matrix per Module52*52
    Pixel Matrix per Panel104*104 / 104*208
    Module Dimensions (L*W) / (mm)250*250
    Module Quality per Cabinet2*2 / 2*4
    Panel Dimension (L*W*H) / (mm)500*500*78 / 500*1000*78
    Panel MaterialDie-Casting Aluminum
    Panel Weight (Kg)6.5 / 13
    Electronic ParameterColor Grayscale (Bit)16
    Gray Scale per Color (Level)65536
    Refresh Rate (Hz)3840
    Driving Type1/13
    Frame Frequency (Hz)50/60
    Signal Transmission Distance (m)CAT5 cable:<100m;Single mode fiber:<10km
    Optical ParameterBrightness (cd/m2)≥5000
    Color Temperature (K)6500-7500
    Color Contrast4000:1
    Optimal Horizontal Viewing Angle (°)160
    Optimal Vertical Viewing Angle160
    Electrical ParameterAC Input Voltage (V)100~240
    AC Input Frequency (Hz)50/60
    AC Input Power Maximum Value (W/m2)800
    AC Input Power Typical Value (W/m2)300
    Circumstance ParameterStorage Temperature (℃)-40~+60
    Operating Temperature (℃)-20~+50
    Storage Humidity (RH)10%~90%
    Operating Humidity (RH)10%~90%
    IP Rating (Front / Rear)IP65 / IP63
    Lifrtime Typical Value (Hrs)100,000
    Installation typeCabinet Installation TypeRental
    Maximum Number of Panel for Lifting12 / 6

    Our services:

    1. Your inquiry about our products or the price will be replied within 8 hours.

    2. We provide 2 years for warranty and lifelong maintaining ,you will appreciate our warm after-sale service.

    3. We will delivery goods as you demand , you can choose the cheaper and more convenient way.

    4. Apart from the Indoor Slim Rental LED Display, PASSION LED also offer you All kinds of outdoor LED Display, LED Flexible Display, Indoor LED Display, Indoor/outdoor LED Signs.


    Application

    Advertising LED display , shopping mall LED display for logo showing , bank &stock exchange LED display for rates showing ,train & bus station , airport ,school message board, telecommunication LED Screen system for information showing and instruction , Stage performance and so on.
