    IP63 Indoor Led Advertising Screen Slim Rental Aluminum Cabinet High Refresh Rate

    Ask Lasest Price
    Brand Name : PASSION
    Model Number : P2.5mm, P3.91mm, P4.81mm
    Certification : CCC, CE, ROHS
    Price : Negotiation
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000sqm/month
    Delivery Time : 10-20 working days
    • Product Details
    • Company Profile

    IP63 Indoor Led Advertising Screen Slim Rental Aluminum Cabinet High Refresh Rate

    led full color display for indoor stage rental, slim aluminum cabinet LED dispplay panel


    Description of Indoor Full Color LED Display:

    1. Usage : Different indoor environment, hotel, night club,shopping mall, meeting room etc

    2. Installation : Mounted-wall, standing on floor. hanging etc

    3. Control : Contolled by your computer ,own equipment.;

    4. Connection : Connected to your computer,Camera or own equipment.

    5. Maintenance: Enough Free spare parts for replacement.,Front service/ Rear service


    Main features of Indoor Full Color LED Display:

    1. SMD3 in 1 technology widens the viewing angle greatly and makes the screen's surface even flatter.
    2. Flatness tolerance of the whole screen is < 0.15 mm, which thoroughly eliminates the mosaic effect.
    3. The screen displays delicate and vivid pictures through synchronous adjustment of color and brightness.
    4. High contrast and high refresh rate help the LED display's image be rendered without any delay, and without leaving any kind of streaks or trails.
    5. Compatible with a variety of signal source inputs, such as AV, S-Video, DVI, VGA, YPbPr, HDMI, SDI, DP, etc.


    Product Specifications of Indoor Full Color LED Display:


    indoor curved p2.976 p3.91 p4.81 p5.95 p6.25 led wall waterproof LED module p2.976 p3.91 p4.81 p5.95 p6.25 indoor curved rental stage ultra slim led screen for concert


    With the light cabinet and good material , installation easily .


    ParameterValue
    Physical ParameterPixel Configuration1R1G1B
    Pixel Pitch (mm)2.5
    Pixel Matrix per m2 (dots)160000
    Pixel Matrix per Module64*64
    Pixel Matrix per Panel192*192
    Module Dimensions (L*W) / (mm)160*160
    Module Quality per Cabinet3*3
    Panel Dimension (L*W*H) / (mm)480*480
    Panel MaterialIron / Aluminum
    Panel Weight (Kg)6
    Electronic ParameterColor Grayscale (Bit)14
    Gray Scale per Color (Level)16384
    Refresh Rate (Hz)1280
    Driving Type1/32
    Frame Frequency (Hz)50/60
    Signal Transmission Distance (m)CAT5 cable:<100m;Single mode fiber:<10km
    Optical ParameterBrightness (cd/m2)≥1000
    Color Temperature (K)6500-7500
    Color Contrast4000:1
    Optimal Horizontal Viewing Angle (°)160
    Optimal Vertical Viewing Angle160
    Electrical ParameterAC Input Voltage (V)100~240
    AC Input Frequency (Hz)50/60
    AC Input Power Maximum Value (W/m2)1100
    AC Input Power Typical Value (W/m2)400
    Circumstance ParameterStorage Temperature (℃)-40~+60
    Operating Temperature (℃)-20~+50
    Storage Humidity (RH)10%~90%
    Operating Humidity (RH)10%~90%
    IP Rating (Front / Rear)IP63 / IP54
    Lifrtime Typical Value (Hrs)100,000
    Installation typeCabinet Installation TypeFixed
    Maximum Number of Panel for Lifting12

    Product Name
    p2.976
    p3.91
    p4.81
    p5.95
    p6.25
    Module size(mm)
    250*250
    Color
    full color
    Brightness
    >2000
    Refresh rate
    >1920 or 3840
    Pixel Density
    112896
    65536
    43264
    28235
    25600
    Working Voltage
    110-240V
    Cabinet size
    500*500mm and 500X1000mm die casting aluminum cabinet

    Application of Indoor Full Color LED Display:
    Indoor HD led display is also called led TV as one of the most popular led display used in TV Studio, Entertainment Center, Surveillance Room, Indoor meeting hall. With small cabinet size: 480 x 480mm, Die-casting aluminum structure with high precision and cooling effect.
