RGB Outdoor Digital Sign Boards 4 Layers PCB Ag Alloy Solder Paster Epistar

    Buy cheap RGB Outdoor Digital Sign Boards 4 Layers PCB Ag Alloy Solder Paster Epistar from wholesalers

    Buy cheap RGB Outdoor Digital Sign Boards 4 Layers PCB Ag Alloy Solder Paster Epistar from wholesalers
    • Buy cheap RGB Outdoor Digital Sign Boards 4 Layers PCB Ag Alloy Solder Paster Epistar from wholesalers
    • Buy cheap RGB Outdoor Digital Sign Boards 4 Layers PCB Ag Alloy Solder Paster Epistar from wholesalers
    • Buy cheap RGB Outdoor Digital Sign Boards 4 Layers PCB Ag Alloy Solder Paster Epistar from wholesalers
    • Buy cheap RGB Outdoor Digital Sign Boards 4 Layers PCB Ag Alloy Solder Paster Epistar from wholesalers

    RGB Outdoor Digital Sign Boards 4 Layers PCB Ag Alloy Solder Paster Epistar

    Ask Lasest Price
    Brand Name : PASSION
    Model Number : P10mm
    Certification : CE , ROSH
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 2000SQm/Month
    Delivery Time : 15 days after deposit payment arrival
    • Product Details
    • Company Profile

    RGB Outdoor Digital Sign Boards 4 Layers PCB Ag Alloy Solder Paster Epistar

    RGB Outdoor Digital Sign Boards 4 Layers PCB Ag Alloy Solder Paster Epistar

    Description:


    1. Advanced SMT encapsulation technology ensure the led lamps in good uniformity,and wide view angle,lower power consumption,energy-saving more than 30%

    2. Good waterproof, IP65 grade, Anti-corrosion,Antifogging,suit for outdoor different weather condition,keep long life time.

    3. High pixel density,High brightness and Long view distance,can be seen from far away 100 meters

    4.Good protection with soft mask and thick bongrace,avoid to be broken and to hurt sportsmen

    5. Brightness can be adjusted automatically according to different surrondings,
    can be set to open and close the screen on fixed automatically

    6. Widely used for commercial advertising, match live broadcasting,sport rebroadcast, company logo, for fixed or for rental use,panel size can be customized according different requirements.


    Product Spefications:
    LED ModulePitch/mmPH10
    Module size/mm160*160
    Density of pixel/(dots/m2)10000
    Pixel composition1R1G1B
    Led encapsulationDIP346
    Resolution of module16*16
    LED ScreenOptimum viewing distance8~100M
    View angleH:±120°;V±60°
    Average power consumption300W/sqm
    Max power consumption1000W/sqm
    Module quantity6 * 6pcs
    Size of cabinet/mm960*960
    Resolution of cabinet96*96
    Cabinet MaterialIron Cabinet (Aluminum Cabinet optional)
    Weight of cabinet55Kg
    Driving method1/4scan constant current
    Frame frequency / Hz/S≥60
    Refresh frequency / Hz/S600~2000
    Brightness7000cd/m2
    Operating temperature–25C°~65C°
    Storage temperature–40C°~70C°
    Operation humidity10%-90%
    Storage humidity10%-90%
    IP Rrating (Front/Rear)IP65/ IP54
    Working vlotageAC220V / AC110V ±10%
    Grey scale/color depthdisplaying colors≥16.7M(synchronized); 14bits
    Brightness adjustment256 levels of each color(manually)
    Input signalRF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
    Control systemlinsn/Colorlight/Nova(sending card,receiving cards and Hubs)
    Average of non-failure life≥50,00h
    Life span≥100,000h
    Functionaless dot rate≤0.0001
    Control distanceCAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km

    All our module chip are from Taiwan Epistar. We guarantee our high quality from the first step !


    All our modules are strictly tested one by one !


    We have special workers to make sure every module works well !


    Our Services

    1. Your inquiry related to our products or price will be replied in 8hrs.
    2. OEM & ODM,any your customized lightings we can help you to design and put into product.
    3. Distributoership are offered for your unique design and some our current models.
    4. Protection of your sales area,ideas of design and all your private information.
    5. Best cost performance and perfect service before and after sales.
