Application Area of Outdoor Advertising LED Display Screen :
Public place:bus,subway, train station, airport, book store, park,
exhibtion hall, stadium, museum,buildings, highway, school, meeting
room, wedding;
Budiness orginazations: supermarket, shopping mall, hotels,
restaurant,hospital;
Financial Orginazations: bank, insurance company, stock company,
pawnshop;
Entertainment: theater, clubs, bars,KTV, internet bars;
Detail Specifications of the Outdoor Advertising LED Display P16mm
model:
| Physical Parameter | Pixel Configuration | 1R1G1B |
| Pixel Pitch (mm) | 16 |
| Pixel Matrix per m2 (dots) | 3906 |
| Pixel Matrix per Module | 16*16 |
| Pixel Matrix per Panel | 64*48 |
| Module Dimensions (L*W) / (mm) | 256*256 |
| Module Quality per Cabinet | 4*3 |
| Panel Dimension (L*W) / (mm) | 1024*768 |
| Panel Material | Iron / Aluminum |
| Panel Weight (Kg) | 45 |
| Electronic Parameter | Color Grayscale (Bit) | 16 |
| Gray Scale per Color (Level) | 16384 |
| Refresh Rate (Hz) | 1280 |
| Driving Type | 1/4 |
| Frame Frequency (Hz) | 50/60 |
| Signal Transmission Distance (m) | CAT5 cable:<100m；Single mode fiber:<10km |
| Optical Parameter | Brightness (cd/m2) | ≥6500 |
| Color Temperature (K) | 6500-7500 |
| Color Contrast | 4000:1 |
| Optimal Horizontal Viewing Angle (°) | 160 |
| Optimal Vertical Viewing Angle | 160 |
| Electrical Parameter | AC Input Voltage (V) | 100~240 |
| AC Input Frequency (Hz) | 50/60 |
| AC Input Power Maximum Value (W/m2) | 1000 |
| AC Input Power Typical Value (W/m2) | 350 |
| Circumstance Parameter | Storage Temperature (℃) | -40~+60 |
| Operating Temperature (℃) | -20~+50 |
| Storage Humidity (RH) | 10%~90% |
| Operating Humidity (RH) | 10%~90% |
| IP Rating (Front / Rear) | IP65 / IP63 |
| Lifrtime Typical Value (Hrs) | 100,000 |
| Installation type | Cabinet Installation Type | Fixed |
| Maximum Number of Panel for Lifting | 6 |
Product Advantages of Outdoor Advertising LED Display Screen :
1. Best equality, commendably solve the problem of the mosaic, have
the excellent consistency of light;
2. Big viewing angle to 140 degree at horizontal line, 140 degree
at vertical line, you can see at every angle, at this range, no
picture change, no color excursion;
3. To pictures and character, have clear, exquisite and real
display effect;
4. High intensity and can be adjusted, so can meet the request of
the customers according to the
application environment;
5. Can repair each led lamps, so the cost of maintain is lower, and
easy to repair
Trade Articles of Outdoor Advertising LED Display Screen :
1) Trade terms: FOB,CIF,EXW
2) Payment terms: T/T ,Western Union, Paypal, Escrow, Moneygram
3) Payment condition: T/T ,30% deposit before production, 70%
balance before delivery
4) Production lead time less 20 sqm: 8-15days, more than 50
sqm:20days. Sample can be deliveried within 3days
5) Shipping: by sea,by air and by express delivery
6) Shipping port: Shenzhen, Mainland China
