6500 Nits Outdoor Advertising LED Display 16 Bits Gray Scale High Brightness

    Buy cheap 6500 Nits Outdoor Advertising LED Display 16 Bits Gray Scale High Brightness from wholesalers

    Buy cheap 6500 Nits Outdoor Advertising LED Display 16 Bits Gray Scale High Brightness from wholesalers
    • Buy cheap 6500 Nits Outdoor Advertising LED Display 16 Bits Gray Scale High Brightness from wholesalers
    • Buy cheap 6500 Nits Outdoor Advertising LED Display 16 Bits Gray Scale High Brightness from wholesalers
    • Buy cheap 6500 Nits Outdoor Advertising LED Display 16 Bits Gray Scale High Brightness from wholesalers
    • Buy cheap 6500 Nits Outdoor Advertising LED Display 16 Bits Gray Scale High Brightness from wholesalers

    6500 Nits Outdoor Advertising LED Display 16 Bits Gray Scale High Brightness

    Ask Lasest Price
    Brand Name : PASSION
    Model Number : P10mm
    Certification : CE ,ROSH
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 2000SQm/Month
    Delivery Time : 15 days after deposit payment arrival
    • Product Details
    • Company Profile

    6500 Nits Outdoor Advertising LED Display 16 Bits Gray Scale High Brightness

    6500nits Outdoor Advertising LED Display 16 Bits Gray Scale High Brightness

    Features of Outdoor Advertising LED Display


    1.Screen can work directly under bright sunshine with brightness >6500nits.


    2.Good quality led chip with low ledattenuation,long lifespan.


    3.With strictly IP65 Rating testing before shipment which ensure the heavy rainy environment using.


    4.Good resistance to deformation with high hardness body,thickness:175mm


    5.With excellent windy,corrosion resistance after surface treatment.


    6.Installation became more easily and fasten.


    Product Description of Outdoor Advertising LED Display :

    P10mm is a by constant current driver IC,control of semiconductor light emitting diode display mode,by controlling the trichromatic lamp brightness changes,showing a variety of colors,display text,images,animation,graphics,quotes,video,video signal display screen


    Mainly used for outdoor high density picture display uses,waterproof and dust proof.Product thin,easy to install and use.


    High brightness to meet the needs of outdoor environment.High gray and high refresh,meet the camera,camera equipment to shoot demand,3535 table stick package,to meet the large angle of view.


    Detail Specifications of the Outdoor Advertising LED Display P10mm model:


    ParameterValue
    Physical ParameterPixel Configuration1R1G1B
    Pixel Pitch (mm)10
    Pixel Matrix per m2 (dots)10000
    Pixel Matrix per Module32*16
    Pixel Matrix per Panel96*96
    Module Dimensions (L*W) / (mm)320*160
    Module Quality per Cabinet3*6
    Panel Dimension (L*W) / (mm)960*960
    Panel MaterialAluminum
    Panel Weight (Kg)35
    Electronic ParameterColor Grayscale (Bit)16
    Gray Scale per Color (Level)16384
    Refresh Rate (Hz)1280
    Driving Type1/4
    Frame Frequency (Hz)50/60
    Signal Transmission Distance (m)CAT5 cable:<100m;Single mode fiber:<10km
    Optical ParameterBrightness (cd/m2)≥6500
    Color Temperature (K)6500-7500
    Color Contrast4000:1
    Optimal Horizontal Viewing Angle (°)160
    Optimal Vertical Viewing Angle160
    Electrical ParameterAC Input Voltage (V)100~240
    AC Input Frequency (Hz)50/60
    AC Input Power Maximum Value (W/m2)1200
    AC Input Power Typical Value (W/m2)400
    Circumstance ParameterStorage Temperature (℃)-40~+60
    Operating Temperature (℃)-20~+50
    Storage Humidity (RH)10%~90%
    Operating Humidity (RH)10%~90%
    IP Rating (Front / Rear)IP65 / IP63
    Lifrtime Typical Value (Hrs)100,000
    Installation typeCabinet Installation TypeFixed
    Maximum Number of Panel for Lifting6

    Trade Articles:

    1) Trade terms: FOB,CIF,EXW

    2) Payment terms: T/T ,Western Union, Paypal, Escrow, Moneygram

    3) Payment condition: T/T ,30% deposit before production, 70% balance before delivery

    4) Production lead time less 20 sqm: 8-15days, more than 50 sqm:20days. Sample can be deliveried within 3days
    5) Shipping: by sea,by air and by express delivery
    6) Shipping port: Shenzhen, Mainland China

    Application Area of Outdoor Advertising LED Display :

    public place:bus,subway, train station, airport, book store, park, exhibtion hall, stadium, museum,buildings, highway, school, meeting room, wedding;

    Budiness orginazations: supermarket, shopping mall, hotels, restaurant,hospital;

    Financial Orginazations: bank, insurance company, stock company, pawnshop;

    Entertainment: theater, clubs, bars,KTV, internet bars;
