    P10 Outdoor Advertising LED Display Screen Iron FrameWith 640mm Cabinet

    Ask Lasest Price
    Brand Name : PASSION
    Model Number : P10mm
    Certification : CE ,ROSH
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 2000SQm/Month
    Delivery Time : 15 days after deposit payment arrival
    • Product Details
    • Company Profile

    P10 Outdoor Advertising LED Display Screen Iron FrameWith 640mm Cabinet

    P10 Outdoor Advertising LED Display Screen Iron FrameWith 640mm Cabinet
    Product Description of Outdoor Advertising LED Display Screen:

    P10mm is a by constant current driver IC,control of semiconductor light emitting diode display mode,by controlling the trichromatic lamp brightness changes,showing a variety of colors,display text,images,animation,graphics,quotes,video,video signal display screen


    Mainly used for outdoor high density picture display uses,waterproof and dust proof.Product thin,easy to install and use.


    High brightness to meet the needs of outdoor environment.High gray and high refresh,meet the camera,camera equipment to shoot demand,3535 table stick package,to meet the large angle of view.


    Application Area of Outdoor Advertising LED Display Screen :

    public place:bus,subway, train station, airport, book store, park, exhibtion hall, stadium, museum,buildings, highway, school, meeting room, wedding;

    Budiness orginazations: supermarket, shopping mall, hotels, restaurant,hospital;

    Financial Orginazations: bank, insurance company, stock company, pawnshop;

    Entertainment: theater, clubs, bars,KTV, internet bars;


    Detail Specifications of the Outdoor Advertising LED Display P10mm model:


    ParameterValue
    Physical ParameterPixel Configuration1R1G1B
    Pixel Pitch (mm)10
    Pixel Matrix per m2 (dots)10000
    Pixel Matrix per Module32*16
    Pixel Matrix per Panel64*64
    Module Dimensions (L*W) / (mm)320*160
    Module Quality per Cabinet2*4
    Panel Dimension (L*W) / (mm)640*640
    Panel MaterialIron / Aluminum
    Panel Weight (Kg)23
    Electronic ParameterColor Grayscale (Bit)14
    Gray Scale per Color (Level)16384
    Refresh Rate (Hz)1280
    Driving Type1/4
    Frame Frequency (Hz)50/60
    Signal Transmission Distance (m)CAT5 cable:<100m;Single mode fiber:<10km
    Optical ParameterBrightness (cd/m2)≥5500
    Color Temperature (K)6500-7500
    Color Contrast4000:1
    Optimal Horizontal Viewing Angle (°)160
    Optimal Vertical Viewing Angle160
    Electrical ParameterAC Input Voltage (V)100~240
    AC Input Frequency (Hz)50/60
    AC Input Power Maximum Value (W/m2)1300
    AC Input Power Typical Value (W/m2)400
    Circumstance ParameterStorage Temperature (℃)-40~+60
    Operating Temperature (℃)-20~+50
    Storage Humidity (RH)10%~90%
    Operating Humidity (RH)10%~90%
    IP Rating (Front / Rear)IP65 / IP63
    Lifrtime Typical Value (Hrs)100,000
    Installation typeCabinet Installation TypeFixed
    Maximum Number of Panel for Lifting8

    Product Advantages of Outdoor Advertising LED Display Screen :

    1. Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light;


    2. Big viewing angle to 140 degree at horizontal line, 140 degree at vertical line, you can see at every angle, at this range, no picture change, no color excursion;


    3. To pictures and character, have clear, exquisite and real display effect;


    4. High intensity and can be adjusted, so can meet the request of the customers according to the

    application environment;


    5. Can repair each led lamps, so the cost of maintain is lower, and easy to repair


    Trade Articles:

    1) Trade terms: FOB,CIF,EXW

    2) Payment terms: T/T ,Western Union, Paypal, Escrow, Moneygram

    3) Payment condition: T/T ,30% deposit before production, 70% balance before delivery

    4) Production lead time less 20 sqm: 8-15days, more than 50 sqm:20days. Sample can be deliveried within 3days
    5) Shipping: by sea,by air and by express delivery
    6) Shipping port: Shenzhen, Mainland China
