    Double Sided Commercial LED Display Screen Wide Viewing Angle 10 Pixel Pitch

    Ask Lasest Price
    Brand Name : PASSION LED
    Model Number : P10 - F
    Certification : CE, ROSH
    Price : Negotiation
    Payment Terms : Western Union, MoneyGram, T/T, , L/C
    Supply Ability : 2000 square meter per month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    Double Sided Commercial LED Display Screen Wide Viewing Angle 10 Pixel Pitch

    Double Sided Commercial LED Display Screen Wide Viewing Angle 10 Pixel Pitch


    Promotion: outdoor Front Service advertising digital display screens with high quality is the most popular for outdoor advertising. It canbe used for outdoor fixed and rental market. You can see this kind of led screen in the shopping mall, airport, train stations, walking street, square, park, Stadium, Plaza, Expo Center, Business Center, CBD, Governmenr Project, High buildings, ect.


    Features of this outdoor advertising fron service display screens


    1) High brightness for outdoor advertising;

    2) Smooth image, DIP(One LED in One Pixel), reduced the amount of LEDs, improved the image effective

    3) More wide viewing angle.

    4) Low cost, high return. Cheap price than other outdoor advertising digital display screenss.


    LED ModulePitch/mmPH10
    Module size/mm160*160
    Density of pixel/(dots/m2)10000
    Pixel composition1R1G1B
    Led encapsulationDIP346
    Resolution of module16*16
    LED ScreenOptimum viewing distance8~100M
    View angleH:±120°;V±60°
    Average power consumption300W/sqm
    Max power consumption1000W/sqm
    Module quantity6 * 6pcs
    Size of cabinet/mm960*960
    Resolution of cabinet96*96
    Cabinet MaterialIron Cabinet (Aluminum Cabinet optional)
    Weight of cabinet55Kg
    Driving method1/4scan constant current
    Frame frequency / Hz/S≥60
    Refresh frequency / Hz/S600~2000
    Brightness7000cd/m2
    Operating temperature–25C°~65C°
    Storage temperature–40C°~70C°
    Operation humidity10%-90%
    Storage humidity10%-90%
    IP Rrating (Front/Rear)IP65/ IP54
    Working vlotageAC220V / AC110V ±10%
    Grey scale/color depthdisplaying colors≥16.7M(synchronized); 14bits
    Brightness adjustment256 levels of each color(manually)
    Input signalRF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
    Control systemlinsn/Colorlight/Nova(sending card,receiving cards and Hubs)
    Average of non-failure life≥50,00h
    Life span≥100,000h
    Functionaless dot rate≤0.0001
    Control distanceCAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km
