1. Lightweight. Convenient in transporting and installing & saving
labor cost, suitable for flow shows.
public place:bus,subway, train station, airport, book store, park,
exhibtion hall, stadium, museum,buildings, highway, school, meeting
room, wedding;
Budiness orginazations: supermarket, shopping mall, hotels,
restaurant,hospital;
Financial Orginazations: bank, insurance company, stock company,
pawnshop;
Entertainment: theater, clubs, bars,KTV, internet bars;
Trade Articles:
1) Trade terms: FOB,CIF,EXW
2) Payment terms: T/T ,Western Union, Paypal, Escrow, Moneygram
3) Payment condition: T/T ,30% deposit before production, 70%
balance before delivery
4) Production lead time less 20 sqm: 8-15days, more than 50
sqm:20days. Sample can be deliveried within 3days
5) Shipping: by sea,by air and by express delivery
6) Shipping port: Shenzhen, Mainland China
Detail Specifications of LED Outdoor Advertising Board:
| LED Module | Pitch/mm | PH10 |
| Module size/mm | 160*160 |
| Density of pixel/(dots/m2) | 10000 |
| Pixel composition | 1R1G1B |
| Led encapsulation | DIP346 |
| Resolution of module | 16*16 |
| LED Screen | Optimum viewing distance | 8~100M |
| View angle | H:±120°;V±60° |
| Average power consumption | 300W/sqm |
| Max power consumption | 1000W/sqm |
| Module quantity | 6 * 6pcs |
| Size of cabinet/mm | 960*960 |
| Resolution of cabinet | 96*96 |
| Cabinet Material | Iron Cabinet (Aluminum Cabinet optional) |
| Weight of cabinet | 55Kg |
| Driving method | 1/4scan constant current |
| Frame frequency / Hz/S | ≥60 |
| Refresh frequency / Hz/S | 600~2000 |
| Brightness | 7000cd/m2 |
| Operating temperature | –25C°～65C° |
| Storage temperature | –40C°～70C° |
| Operation humidity | 10%-90% |
| Storage humidity | 10%-90% |
| IP Rrating (Front/Rear) | IP65/ IP54 |
| Working vlotage | AC220V / AC110V ±10% |
| Grey scale/color depth | displaying colors≥16.7M(synchronized); 14bits |
| Brightness adjustment | 256 levels of each color(manually) |
| Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc |
| Control system | linsn/Colorlight/Nova(sending card,receiving cards and Hubs) |
| Average of non-failure life | ≥50,00h |
| Life span | ≥100,000h |
| Functionaless dot rate | ≤0.0001 |
| Control distance | CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km |
